Redding 22 Arc Type S Full Length Bushing Die
$98.36
The Redding 22 Arc Type S Full Length Bushing Die gives reloaders precision control over case neck sizing without sacrificing full-length resizing in a single pass. This is the die to reach for when you're working up loads for a 22 ARC precision rifle and want the consistency that comes from managing case neck concentricity and neck tension independently. The Type S bushing design is Redding's answer to shooters who need fine-tuned neck control on production brass without the extra steps.
What sets this die apart is the interchangeable bushing system that adjusts in .001" increments, letting you dial in the exact amount of neck sizing your brass demands. The bushing itself self-centers on the case neck as it sizes, which means better concentricity and more consistent results downrange. The adjustable decapping rod gives you the flexibility to resize only part of the neck length if that's what your load development calls for—useful when you're fine-tuning and want to experiment with neck tension variables.
Like all Redding Type S dies, this one ships with both a standard size button and a decapping pin retainer so you can adapt it to your specific workflow. If you ever need a body die down the road, the Type S design lets you convert it by removing the bushing and internal parts. That kind of versatility fits the reloader who's in this hobby for the long haul and wants equipment that earns its place in the press.
Key Features
- Full-length case resizing with independent neck control in one operation
- Interchangeable bushings with .001" increment adjustments for precise neck sizing
- Bushing self-centers on case neck for enhanced concentricity
- Adjustable decapping rod allows partial neck sizing when needed
- Supplied with standard size button and decapping pin retainer
- Convertible to a body die by removing internal components
Specifications
| Caliber | 22 ARC |
| Die Type | Type S Full Length Bushing Die |
| Bushing Adjustment | .001" increments |
| Manufacturer | Redding |
Frequently Asked Questions
Can I use this die to resize only the neck instead of the full length?
Yes. The adjustable decapping rod lets you position the bushing to resize only part of the neck length when you want to experiment with different neck tension approaches or prefer partial-length sizing for your 22 ARC loads.
What's included with the die?
The die ships with both a standard size button and a decapping pin retainer, giving you the flexibility to choose the setup that best fits your reloading workflow.
Can this die work as a body die?
Yes. If you remove the bushing and all internal components, the Type S design allows you to use it as a body die—a handy feature if your reloading needs expand over time.
How do the interchangeable bushings work?
The bushings adjust in .001" increments and self-center on the case neck as it sizes, which enhances concentricity and gives you precise control over how much neck tension you're applying to your ammunition.
